Dual-Monitor Thunderbolt 3 to DisplayPort Adapter - 4K/5K @ 60 Hz, M/2xF, 4:4:4, Silver
Universal Compatibility Across Formats
Eaton’s Tripp Lite series audio/video adapters ensure seamless connectivity, high‑quality signal transmission and future‑ready performance for IT, business, education and entertainment environments. There is an adapter for virtually every video standard in use today, including HDMI, DisplayPort, USB-C and Thunderbolt. Whether you’re adapting a modern USB‑C laptop to a legacy VGA projector or driving an 8K DisplayPort monitor from a Thunderbolt dock, this line of audio/video adapters ensure compatibility without compromise.
Keep Your Network Connected, Clear and Ready for Upgrading
In addition to connecting laptops, desktops, tablets and media players to monitors, projectors and televisions, these audio/video adapters provide:
Simplified Connectivity and Flexibility
The adapters are plug‑and‑play, requiring no drivers or software. Compact and lightweight, they’re perfect for travel, hot‑desking and hybrid work environments. This flexibility allows you to standardize on a single family of adapters that cover every scenario, reducing complexity and costs.
| Product Name |
Eaton Tripp Lite series video adapter
|
| Catalog Number |
MTB3-002-DP
|
| UPC |
037332222008
|
| Product Length/Depth |
3.94 in
|
| Product Height |
0.91 in
|
| Product Width |
5.5 in
|
| Product Weight |
0.001 lb
|
| Global Catalog |
MTB3-002-DP
|
| Product Type |
Video adapter
|
| Application |
|
| Operating Humidity Range |
10% to 90% RH (No Condensation)
|
| Storage Humidity Range |
10% to 90% RH (No Condensation)
|
| Color |
Silver
|
| Cable Jacket Rating |
VW-1
|
| Connector Plating |
Nickel
|
| Product Features |
Bus Powered
HDR Support 3D Video Supported |
| Cable Jacket Material |
TPE
|
| Color Depth |
48-bit Deep color
|
| Product Highlights |
Supports a single DisplayPort monitor at 5K resolutions of 5120 x 2880 @ 60 Hz
Works with Mac and Windows computers and laptops with Thunderbolt 3 output Supports dual DisplayPort monitors at 4K resolutions of 3840 x 2160 @ 60 Hz Plug-and-play operation with no software required for easy, immediate installation Reversible Thunderbolt 3 plug connects in either direction for instant no-fuss use |
| Chroma Sub Sampling |
4:2:2
4:4:4 |
| Plug Color |
White
Blue |
| HDCP Specification |
2.2
|
| SideA Connector1 |
THUNDERBOLT 3 (Type-C MALE)
|
| SideB Connector1 |
DISPLAYPORT (FEMALE)
|
| SideB Connector2 |
DISPLAYPORT (FEMALE)
|
| Displayport Specification |
1.4
|
| Technology |
Thunderbolt
DisplayPort |
| Features |
Flex Center
|
| Storage Temperature Range |
14° to 158°F (-10° to 70°C)
|
| Max Supported Video Resolution |
3840 x 2160 (4K x 2K) @ 60Hz (Dual Displays); 5120 × 2880 (5K x 2K) @ 60Hz (Single Display)
|
| Thunderbolt Specification |
Thunderbolt 3 (up to 40Gbps short or active cables)
|
